Printers & POSASUS ROG Thor Platinum II - power supply - 1000 Watt
SKU 90YE00L4-B0NA00
| Product Description: | ASUS ROG Thor Platinum II - power supply - 1000 Watt |
| Device Type: | Power supply - internal |
| Specification Compliance: | ATX12V |
| 80 PLUS Certification: | 80 PLUS Platinum |
| Weight: | 2.37 kg |
| Input Voltage: | AC 100-240 V |
| Output Voltage: | +3.3, +5, ±12 V |
- Specifications
- Description
| General | |
| Device Type: | Power supply - internal |
| Specification Compliance: | ATX12V |
| PSU Form Factor: | ATX |
| Power Device | |
| Input Voltage: | AC 100-240 V |
| Power Output Connectors Details: | 1 x power 24 pin ATX with detachable 4 pin section ¦ 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 1 x 12 pin PCI Express power ¦ 8 x 8 pin PCI Express power with detachable 2 pin section ¦ 12 x 15 pin Serial ATA power |
| Output Voltage: | +3.3, +5, ±12 V |
| Power Capacity: | 1000 Watt |
| Output Current: | +3.3V - 25 A ¦ +5V - 25 A ¦ +12V - 83 A ¦ -12V - 0.3 A ¦ +5VSB - 3 A |
| Efficiency: | 92% |
| Modular Cable Management: | Yes |
| 80 PLUS Certification: | 80 PLUS Platinum |
| Miscellaneous | |
| Included Accessories: | Screws, 12 cable ties, ROG sticker, 6 x ROG cable ties, cable combs |
| Cables Included: | AC input cable - external ¦ Power 24 pin ATX with detachable 4 pin section modular cable 61 cm ¦ 2 x power 8 pin +12V with detachable 4 pin section modular cable 65 cm ¦ 16-pin 12VHPWR power cable 67.5 cm ¦ 4 x 8 pin PCI Express power with detachable 2 pin section modular cable 67.5 cm ¦ 2 x 2x 8 pin PCI Express power with detachable 2 pin section modular cable ¦ 3 x Serial ATA cable ¦ ARGB sync cable ¦ 2 x 4 pin internal power cable |
| Cooling System: | 135 mm fan |
| Features: | Sleeved cables, over current protection, over voltage protection, overpower protection, undervoltage protection, short-circuit protection, dual ball bearing cooling fan, thermal protection, OLED display, fully modular, ASUS Aura Sync, ROG heatsink, Axial-tech fan design, 0db Technology, Lambda A++ Certification |
| Compliant Standards: | C-Tick, CB, CCC, FCC, RoHS, WEEE, TUV SUD, EAC |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - 10 years ¦ Limited warranty - OLED panel - 3 years ¦ Limited warranty - RGB LEDs - 3 years |
| Dimensions & Weight | |
| Width: | 15 cm |
| Depth: | 19 cm |
| Height: | 8.6 cm |
| Weight: | 2.37 kg |
The ROG Thor 1000 W Platinum wields cooling and component upgrades that make it an extremely quiet PSU. And to complement premium motherboards and bring additional flair to beastly rigs, there is a mirrored side panel that neatly frames the OLED display.
- Lambda A++ Certification confirms the Thor wields menacing power in absolute stealth
- ROG heatsinks cover critical components, delivering lower temperatures and reduced noise
- A 135 mm Axial-tech fan with PWM control delivers lower noise and keeps thermals in check
- Built with low-ESR capacitors and other premium components to achieve 80 Plus Platinum Certification
- OLED display monitors power draw in real time
- Aura Sync compatibility lets you customize and sync lighting effects with other compatible hardware
The technical details come from 3rd party. edgemo is not responsible for any errors.
