ASUS ROG Strix - Aura Edition - power supply - 1200 Watt
SKU 90YE00P0-B0NA00
Product Description: | ASUS ROG Strix - Aura Edition - power supply - 1200 Watt |
Device Type: | Power supply - internal |
Specification Compliance: | ATX12V 3.0/ EPS12V |
80 PLUS Certification: | 80 PLUS Gold |
Weight: | 3.23 kg |
Input Voltage: | AC 100-240 V |
Output Voltage: | +3.3, +5, ±12 V |
- Specifications
- Description
General | |
Device Type: | Power supply - internal |
Specification Compliance: | ATX12V 3.0/ EPS12V |
PSU Form Factor: | ATX |
Power Device | |
Input Voltage: | AC 100-240 V |
Power Output Connectors Details: | 1 x power 24 pin ATX with detachable 4 pin section ¦ 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 1 x 16 pin PCI Express power ¦ 3 x 8 pin PCI Express power ¦ 5 x 15 pin Serial ATA power ¦ 4 x 4 PIN internal power |
Output Voltage: | +3.3, +5, ±12 V |
Power Capacity: | 1200 Watt |
Output Current: | +3.3V - 22 A ¦ +5V - 22 A ¦ +12V - 100 A ¦ -12V - 0.3 A ¦ +5VSB - 3 A |
Modular Cable Management: | Yes |
80 PLUS Certification: | 80 PLUS Gold |
Miscellaneous | |
Cables Included: | AC input cable - external ¦ Power 24 pin ATX with detachable 4 pin section modular cable 60 cm ¦ 2 x power 8 pin +12V with detachable 4 pin section modular cable 65 cm ¦ 16-pin 12VHPWR power cable 70 cm ¦ 2x 8 pin PCI Express power with detachable 2 pin section modular cable 70 cm ¦ 8 pin PCI Express power with detachable 2 pin section modular cable 70 cm ¦ ARGB sync cable 80 cm ¦ 3x Serial ATA modular cable ¦ 2x Serial ATA modular cable ¦ 4 pin internal power cable |
Cooling System: | 135 mm fan |
Features: | Overheat protection, over current protection, over voltage protection, overpower protection, undervoltage protection, short-circuit protection, dual ball bearing cooling fan, fully modular, ASUS Aura Sync, ROG heatsink, Axial-tech fan design, aluminium enclosure, 0dB fan button, Cybenetics A+ |
Compliant Standards: | RoHS |
Manufacturer Warranty | |
Service & Support: | Limited warranty - 10 years ¦ Limited warranty - RGB LEDs - 3 years |
Dimensions & Weight | |
Width: | 15 cm |
Depth: | 18 cm |
Height: | 8.6 cm |
Weight: | 3.23 kg |
The ROG Strix 1000 W Gold Aura combines premium components, superior cooling and captivating RGB illumination to create a formidable force. With huge ROG heatsinks, a high efficiency Axial-tech fan, and a striking aluminum finish, it's a pumped-and-primed PSU powerhouse for your next gaming rig.
- Built to run cool
- Heart of gold
- Outshine the competition
