Printers & POSASUS Pro E500 G6 - tower - AI Ready - no CPU - 0 GB - no HDD
SKU 90SF0181-M00380
| Product Description: | ASUS Pro E500 G6 - tower - AI Ready - no CPU - 0 GB - no HDD |
| Type: | Workstation - tower AI Ready |
| Processor: | No CPU |
| Processor Socket: | LGA1200 Socket |
| RAM: | 0 GB (installed) / 128 GB (max) - DDR4 SDRAM - ECC |
| Storage Controller: | RAID (SATA 6Gb/s) |
| Hard Drive: | No HDD |
- Specifications
- Description
| General | |
| Type: | Workstation - AI Ready |
| Product Form Factor: | Tower |
| Processor / Chipset | |
| CPU: | No CPU |
| Max CPU Qty: | 1 |
| CPU Upgradability: | Upgradable |
| CPU Socket: | LGA1200 Socket |
| Chipset Type: | Intel W480 |
| RAM | |
| Installed Size: | 0 GB (installed) / 128 GB (max) |
| Technology: | DDR4 SDRAM - ECC |
| Form Factor: | DIMM 288-pin |
| Slots: | 4 (Total) / 4 (empty) |
| Features: | Unbuffered, dual channel memory architecture |
| Hard Drive | |
| Type: | No HDD |
| Storage Controller | |
| Type: | 1 x RAID |
| Controller Interface Type: | SATA 6Gb/s |
| Channel Qty: | 8 |
| RAID Level: | RAID 0, RAID 1, RAID 5, RAID 10 |
| Optical Storage | |
| Type: | No optical drive |
| Monitor | |
| Monitor Type: | None. |
| Graphics Controller | |
| Graphics Processor: | No graphics |
| Audio Output | |
| Sound Output Mode: | 7.1 channel surround |
| Compliant Standards: | High Definition Audio |
| Networking | |
| Ethernet Ports: | 1 x 2.5 Gigabit Ethernet, 1 x Gigabit Ethernet |
| Ethernet Controller: | Intel I219-LM, I225-LM |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Expansion / Connectivity | |
| Bays: | 3 (total) / 3 (free) x internal 3.5" ¦ 3 (total) / 3 (free) x external 5.25" ¦ 1 (total) / 1 (free) x internal 2.5" |
| Slots: | 2 (total) / 2 (free) x PCIe 3.0 x16 - full-length, full-height (x4 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height (x16/x8 mode) ¦ 1 (total) / 1 (free) x M.2 Card - 22110 ¦ 1 (total) / 1 (free) x M.2 Card - 2280 ¦ 2 (total) / 2 (free) x PCIe 3.0 x1 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height (x0/x8 mode) |
| Interfaces: | 1 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x TOSLINK ¦ 6 x USB 3.2 Gen 1 (2 front, 4 rear) ¦ 1 x headphones (1 in front) ¦ 2 x microphone (1 front, 1 rear) ¦ 1 x audio line-in ¦ 1 x audio line-out ¦ 1 x audio line-out (centre/subwoofer) ¦ 1 x audio line-out (rear) ¦ 1 x USB 3.2 Gen 2 ¦ 1 x USB-C 3.2 Gen 2 ¦ 2 x USB 2.0 (2 in front) ¦ 1 x HDMI ¦ 1 x DisplayPort ¦ 1 x DVI-D ¦ 1 x VGA ¦ 1 x LAN (2.5Gigabit Ethernet) |
| Miscellaneous | |
| Compliant Standards: | FCC Class B certified, BSMI |
| Power | |
| Device Type: | Power supply |
| Operating System / Software | |
| OS Provided: | No operating system |
| Sustainability Information | |
| ENERGY STAR Certified: | Yes |
| Dimensions & Weight | |
| Width: | 19 cm |
| Depth: | 43.5 cm |
| Height: | 42.3 cm |
| Weight: | 9.9 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Weight: | 12.1 kg |
| Environmental Parameters | |
| Min Operating Temperature: | 10 °C |
| Max Operating Temperature: | 35 °C |
Pro E500 G6 is an essential workstation that delivers professional performance and flexible expandability ideal for a range of applications from design to virtualization.
- Supports up to three independent displays simultaneously via HDMI, DisplayPort, DVI-D and VGA
- Dual M.2 for up to 32Gbps performance and data redundancy
The technical details come from 3rd party. edgemo is not responsible for any errors.
