Printers & POSASUS PRIME N100I-D D4 - motherboard - mini ITX - Intel N-series N100
SKU 90MB1F70-M0EAYC
| Product Description: | ASUS PRIME N100I-D D4 - motherboard - mini ITX - Intel N-series N100 |
| Product Type: | Motherboard - mini ITX |
| Processor: | Intel N-series N100 / 3.4 GHz (Quad-Core) |
| Processor Socket: | 1 |
| Max RAM Size: | 16 GB |
| RAM Supported: | 1 SO-DIMM slot - DDR4, non-ECC, unbuffered |
| Storage Ports: | 1 x SATA-600, 1 x M.2 |
- Specifications
- Description
| General | |
| Product Type: | Motherboard - mini ITX |
| Processor: | Intel N-series N100 / 3.4 GHz (Quad-Core) |
| Max Processors Qty: | 1 |
| Supported RAM | |
| Max Size: | 16 GB |
| Technology: | DDR4 |
| Bus Clock: | 2400 MHz, 2133 MHz, 2800 MHz, 2666 MHz, 2933 MHz, 3200 MHz |
| Supported RAM Integrity Check: | Non-ECC |
| Registered or Buffered: | Unbuffered |
| Audio | |
| Type: | HD Audio (8-channel) |
| Compliant Standards: | High Definition Audio |
| LAN | |
| Network Interfaces: | Gigabit Ethernet |
| Expansion / Connectivity | |
| Expansion Slots: | 1 x SO-DIMM 260-pin ¦ PCIe 3.0 x1 ¦ M.2 socket (2260/2280 M.2 Key M slot) ¦ M.2 socket (for Intel CNVi wireless module) |
| Storage Interfaces: | SATA-600 -connectors: 1 x 7pin Serial ATA ¦ PCIe 3.0 -connectors: 1 x M.2 |
| Interfaces: | 1 x HDMI ¦ 1 x VGA ¦ 1 x DisplayPort ¦ 2 x USB 3.2 Gen 2 ¦ 2 x USB 3.2 Gen 1 ¦ 2 x USB 2.0 ¦ 1 x serial ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x PS/2 keyboard / mouse ¦ 1 x audio line-in - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x audio line-out - mini-jack |
| Internal Interfaces: | 2 x USB 3.2 Gen 1 - header ¦ 2 x USB 2.0 - header ¦ 1 x serial - header ¦ 1 x audio - header ¦ 1 x SPDIF out - header ¦ 1 x SPI - header ¦ 1 x speaker - header |
| Power Connectors: | 4-pin ATX12V connector, 24-pin main power connector |
| Features | |
| BIOS Type: | AMI |
| BIOS Features: | UEFI BIOS, ASUS EZ Flash 3 |
| Sleep / Wake Up: | Wake on LAN (WOL), wake on PME |
| Hardware Features: | ASUS Q-Design, ESD Guards, ASUS EZ DIY, CrashFree BIOS 3, Intel Turbo Boost Technology 2.0, Fanless Design Heatsink, ASUS Stainless Steel Back I/O, LANGuard, overvoltage protection, Q-LED Core |
| Miscellaneous | |
| Included Accessories: | IO shield, M.2 screw package, M.2 Key E screw package |
| Cables Included: | 2 x Serial ATA cable |
| Software Included: | ASUS CPU-Z, WinRAR, Norton 360 Deluxe (60 days trial) |
| Width: | 17 cm |
| Depth: | 17 cm |
The ASUS PRIME N100I-D D4 motherboard offers a compact design with robust features catering to various computing needs. Equipped with an Intel N-series processor, this mini ITX motherboard supports DDR4 SDRAM with speeds ranging from 2133 MHz to 3200 MHz, providing flexibility for applications. With support for high definition audio and multiple connectivity options including HDMI, USB 3.2, and Gigabit Ethernet, this product ensures reliable performance and seamless multimedia experiences. The motherboard features a PCIe 3.0 x1 expansion slot and an M.2 socket, allowing for enhanced storage options. Its user-friendly BIOS features such as UEFI BIOS and ASUS EZ Flash 3 enhance system management and customization. Coupled with a fanless design heatsink and ASUS ESD Guards, this motherboard is engineered for longevity and efficiency.
- Supports DDR4 SDRAM with various speed options
- Equipped with multiple USB 3.2 and HDMI ports for versatile connectivity
- Includes PCIe 3.0 x1 and M.2 socket for added expansion
- Features UEFI BIOS for easy system management
- Designed with a fanless heatsink for quiet operation
The technical details come from 3rd party. edgemo is not responsible for any errors.
