ASUS PRIME B760M-A D4-CSM - motherboard - micro ATX - LGA1700 Socket - B760

SKU PRIME B760M-A D4-CSM
Product Description:ASUS PRIME B760M-A D4-CSM - motherboard - micro ATX - LGA1700 Socket - B760
Product Type:Motherboard - micro ATX
Chipset Type:Intel B760
Processor Socket:1 x LGA1700 Socket
Compatible Processors:(supports 12th and 13th Generation Intel Core / Pentium Gold / Celeron)
Max RAM Size:128 GB
RAM Supported:4 DIMM slots non-ECC, unbuffered
Not in stock
Login for price
  • Specifications
  • Description
  • Accessories
General
Product Type:Motherboard - micro ATX
Chipset Type:Intel B760
Processor Socket:LGA1700 Socket
Max Processors Qty:1
Compatible Processors:(supports 12th and 13th Generation Intel Core / Pentium Gold / Celeron)
Supported RAM
Max Size:128 GB
Bus Clock:2400 MHz, 2133 MHz, 2800 MHz, 3000 MHz, 2666 MHz, 2933 MHz, 3400 MHz (O.C.), 3333 MHz (O.C.), 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 4000 MHz (O.C.), 4400 MHz (O.C.), 4266 MHz (O.C.), 4600 MHz (O.C.), 4800 MHz (O.C.), 3200 MHz, 5000 MHz (O.C.), 5066 MHz (O.C.), 5333 MHz (O.C.)
Supported RAM Integrity Check:Non-ECC
Registered or Buffered:Unbuffered
Features:Dual channel memory architecture, Intel Extreme Memory Profiles (XMP)
Audio
Type:HD Audio (8-channel)
Compliant Standards:High Definition Audio
LAN
Network Interfaces:2.5 Gigabit Ethernet
Expansion / Connectivity
Expansion Slots:1 x CPU ¦ 4 x DIMM 288-pin ¦ 1 x PCIe 4.0 x16 ¦ 1 x PCIe 4.0 x16 (x4 mode) ¦ 1 x PCIe 4.0 x16 (x1 mode) ¦ 2 x M.2 socket (2242/2260/2280 M.2 Key M slot)
Storage Interfaces:SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ PCIe 4.0 -connectors: 2 x M.2
Interfaces:2 x HDMI ¦ 1 x DisplayPort ¦ 2 x USB 3.2 Gen 2 ¦ 4 x USB 2.0 ¦ 1 x LAN (2.5Gigabit Ethernet) ¦ 1 x PS/2 keyboard / mouse ¦ 1 x microphone - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack
Internal Interfaces:5 x USB 2.0 - header ¦ 1 x USB-C 3.2 Gen 1 - header ¦ 4 x USB 3.2 Gen 1 - header ¦ 1 x serial - header ¦ 1 x SPI - header ¦ 1 x SPDIF out - header ¦ 1 x audio - header
Power Connectors:24-pin main power connector, 8-pin ATX12V connector
Features
BIOS Type:AMI
BIOS Features:UEFI BIOS, ASUS EZ Flash 3, ASUS UEFI BIOS EZ Mode
Sleep / Wake Up:Wake on LAN (WOL), wake on PME
Hardware Features:ASUS Q-Design, Q-DIMM, ASUS EZ DIY, Q-Slot, CrashFree BIOS 3, Intel Turbo Boost Technology 2.0, ASUS DIGI+ VRM, Preboot eXecution Environment (PXE), ASUS Stainless Steel Back I/O, ASUS Fan Xpert 2+, LANGuard, ASUS Overvoltage Protection, ASUS 5X Protection III, ASUS ProCool, Intel Turbo Boost Max Technology 3.0, ASUS Aura Sync, ASUS OptiMem II, ASUS SafeSlot Core+, Q-LED Core, VRM heatsink design
Miscellaneous
Included Accessories:IO shield, 1 x M.2 rubber package, ACC Express Activation Key Card, M.2 SSD screw package
Cables Included:2 x Serial ATA cable
Software Included:ASUS CPU-Z, ASUS AI Suite III, PC Cleaner, WinRAR, ASUS AURA Creator, Armoury Crate, Norton 360 Deluxe (60 days trial)
Width:24.4 cm
Depth:24.4 cm
vis mere
The ASUS PRIME B760M-A D4-CSM motherboard is designed to cater to the needs of both gaming enthusiasts and professional users. It supports 12th and 13th Generation Intel Core, Pentium Gold, and Celeron processors on the LGA1700 socket, offering a powerful foundation for your next PC build. With support for DDR4 SDRAM at speeds up to 5333 MHz (O.C.) across 4 DIMM slots, it provides ample capacity for memory-intensive applications and multitasking.
This motherboard is equipped with a comprehensive cooling setup, including ASUS Fan Xpert 2+ and a VRM heatsink design, ensuring that your system remains cool and stable under load. The dual M.2 sockets and 4 x SATA-600 (RAID) storage interfaces allow for fast data transfer and flexible storage options, including RAID configurations for enhanced data integrity and speed. Networking is handled by a 2.5 Gigabit Ethernet port, offering a significant upgrade over standard Gigabit connections for faster, more reliable network performance.
For those looking to personalize their setup, ASUS Aura Sync provides a vast ecosystem of compatible devices for synchronized RGB lighting effects across your entire gaming environment. The motherboard's durability is bolstered by ASUS 5X Protection III, including overvoltage protection and a stainless steel back I/O, ensuring long-term reliability and stability. Whether you're building a high-performance gaming rig or a powerful workstation, the ASUS PRIME B760M-A D4-CSM offers a solid foundation with a balance of features and performance.
  • Supports 12th and 13th Generation Intel Core processors for advanced performance
  • Dual M.2 sockets and 4 x SATA-600 (RAID) for high-speed storage solutions
  • 2.5 Gigabit Ethernet for fast networking capabilities
  • ASUS Aura Sync for customizable and synchronized RGB lighting
  • Intel Extreme Memory Profiles (XMP) support for hassle-free overclocking




The technical details come from 3rd party. edgemo is not responsible for any errors.
