ASUS H110M-R - motherboard - micro ATX - LGA1151 Socket - H110

SKU 90MB0QN0-M0ECY0
Product Description:ASUS H110M-R - motherboard - micro ATX - LGA1151 Socket - H110
Product Type:Motherboard - micro ATX
Chipset Type:Intel H110 Express
Processor Socket:1 x LGA1151 Socket
Compatible Processors:Pentium, Celeron, Core i5, Core i3, Core i7
Max RAM Size:32 GB
RAM Supported:2 DIMM slots - DDR4, non-ECC, unbuffered
Not in stock
  • Specifications
  • Description
General
Product Type:Motherboard - micro ATX
Chipset Type:Intel H110 Express
Processor Socket:LGA1151 Socket
Max Processors Qty:1
Compatible Processors:Pentium, Celeron, Core i5, Core i3, Core i7
Supported RAM
Max Size:32 GB
Technology:DDR4
Bus Clock:2133 MHz
Supported RAM Integrity Check:Non-ECC
Registered or Buffered:Unbuffered
Features:Dual channel memory architecture, Intel Extreme Memory Profiles (XMP)
Graphics
Max Allocated RAM Size:1024 MB
Audio
Type:HD Audio (8-channel)
Audio Codec:Realtek ALC887
Compliant Standards:High Definition Audio
LAN
Network Controller:Realtek RTL8111H
Network Interfaces:Gigabit Ethernet
Expansion / Connectivity
Expansion Slots:1 x CPU ¦ 2 x DIMM 288-pin ¦ 1 x PCIe 3.0 x16 ¦ 2 x PCIe 2.0 x1
Storage Interfaces:SATA-600 -connectors: 4 x 7pin Serial ATA - 4 devices
Interfaces:2 x USB 3.0 ¦ 4 x USB 2.0 ¦ 1 x VGA ¦ 1 x audio line-out - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x PS/2 keyboard ¦ 1 x PS/2 mouse ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x DVI ¦ 1 x HDMI
Internal Interfaces:2 x USB 2.0 - header ¦ 2 x USB 3.0 - header ¦ 1 x audio - header ¦ 1 x parallel - header ¦ 1 x serial - header
Power Connectors:4-pin ATX12V connector, 24-pin main power connector
Features
BIOS Type:AMI
BIOS Features:DMI 2.0 support, WfM 2.0 support, Multilingual BIOS, ASUS Quiet Thermal Solution, UEFI BIOS, ACPI 5.0 support, ASUS EZ Flash 3, SMBIOS 3.0 support
Sleep / Wake Up:Wake on LAN (WOL), wake on PME
Hardware Features:ASUS Q-Design, Q-DIMM, ASUS EZ DIY, Q-Slot, CrashFree BIOS 3, ASUS EPU (Energy Processing Unit), Intel Extreme Memory Profile (XMP) support, ASUS Fan Xpert, Intel Turbo Boost Technology 2.0, ASUS DIGI+ VRM, ASUS Enhanced DRAM Overcurrent Protection, Preboot eXecution Environment (PXE), ASUS Stainless Steel Back I/O, LANGuard, ASUS 5X Protection II, overvoltage protection
Miscellaneous
Included Accessories:I/O back plate
Cables Included:2 x Serial ATA cable
Software Included:Drivers & Utilities, ASUS AI Charger, ASUS AI Suite III, ASUS EZ Update, Antivirus (OEM version), Mobo Connect, Media Streamer, ASUS EZ Flash 3
Compliant Standards:Plug and Play, ACPI 5.0
Width:21.08 cm
Depth:18.03 cm
Package Type:OEM




The technical details come from 3rd party. edgemo is not responsible for any errors.
