Printers & POSASUS ExpertCenter PN54 S50016H - mini PC Ryzen AI 5 340 2 GHz - 16 GB - SSD 512 GB
SKU 90MS02Y1-M00050
| Product Description: | ASUS ExpertCenter PN54 S50016H - mini PC Ryzen AI 5 340 2 GHz - 16 GB - SSD 512 GB |
| Type: | Personal computer - mini PC |
| Processor: | AMD Ryzen AI 5 340 / 2 GHz (up to 4.8 GHz, (6-core) |
| Neural Processor Unit (NPU): | - up to 50 TOPS |
| Cache Memory: | 16 MB |
| Cache Per Processor: | 16 MB |
| RAM: | 16 GB (installed) / 64 GB (max) - DDR5 SDRAM |
- Specifications
- Description
| General | |
| Type: | Personal computer |
| Product Form Factor: | Mini PC |
| Built-in Devices: | Fingerprint reader |
| Embedded Security: | Firmware Trusted Platform Module (fTPM 2.0) |
| Colour: | Black |
| Processor / Chipset | |
| CPU: | AMD Ryzen AI 5 340 |
| Clock Speed: | 2 GHz |
| Max Turbo Speed: | 4.8 GHz |
| Number of Cores: | 6-core |
| CPU Qty: | 1 |
| Max CPU Qty: | 1 |
| Neural Processor Unit (NPU) | |
| NPU Performance Up To (TOPS): | 50 TOPS |
| Total Processor Performance Up To (TOPS): | 59 TOPS |
| Cache Memory | |
| Installed Size: | 16 MB |
| Cache Per Processor: | 16 MB |
| RAM | |
| Installed Size: | 16 GB (installed) / 64 GB (max) |
| Technology: | DDR5 SDRAM |
| Effective Memory Speed: | 5600 MT/s |
| Rated Memory Speed: | 5600 MT/s |
| Form Factor: | SO-DIMM 262-pin |
| Slots: | 2 (Total) / 0 (empty) |
| Configuration Features: | 2 x 8 GB |
| Hard Drive | |
| Type: | SSD - M.2 2280 |
| Capacity: | 1 x 512 GB |
| Interface Type: | PCI Express 4.0 |
| Features: | NVM Express (NVMe) |
| Optical Storage | |
| Type: | No optical drive |
| Monitor | |
| Monitor Type: | None. |
| Graphics Controller | |
| Graphics Processor: | AMD Radeon 840M |
| Video Interfaces: | HDMI, DisplayPort |
| Audio Output | |
| Speakers Included: | 2 x right / left channel |
| Networking | |
| Ethernet Ports: | 2 x 2.5 Gigabit Ethernet |
| Wireless LAN Supported: | Yes |
| Data Link Protocol: | 2.5 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11be (Wi-Fi 7), IEEE 802.11g, IEEE 802.11n, Bluetooth 5.4 |
| Features: | Dual stream (2x2) |
| Expansion / Connectivity | |
| Interfaces: | LAN (2.5Gigabit Ethernet) ¦ USB 2.0 ¦ 3 x USB 3.2 Gen 2 ¦ 1 x USB-C 3.2 Gen 2 ¦ 1 x headphones/microphone ¦ 1 x HDMI ¦ 2 x DisplayPort 1.4 ¦ 1 x USB4 |
| Miscellaneous | |
| Theft/Intrusion Protection: | Security lock slot (cable lock sold separately) |
| Security Slot Type: | Kensington security slot |
| Compliant Standards: | UL, VCCI, C-Tick, BSMI, CB, CCC, FCC |
| Power | |
| Device Type: | Power adapter |
| Power Provided: | 120 Watt |
| Operating System / Software | |
| OS Provided: | Windows 11 |
| Copilot+ PC: | Yes |
| Dimensions & Weight | |
| Width: | 13 cm |
| Depth: | 13 cm |
| Height: | 3.4 cm |
| Weight: | 550 g |
The technical details come from 3rd party. edgemo is not responsible for any errors.
