Printers & POSASUS AT3IONT-I - motherboard - mini ITX - Intel Atom 330 - NVIDIA ION
SKU AT3IONT-I
| Product Description: | ASUS AT3IONT-I - motherboard - mini ITX - Intel Atom 330 - NVIDIA ION |
| Product Type: | Motherboard - mini ITX |
| Processor: | Intel Atom 330 (Dual-Core) |
| Chipset Type: | NVIDIA ION |
| Max RAM Size: | 4 GB |
| RAM Supported: | 2 DIMM slots - DDR3, non-ECC, unbuffered |
| Storage Ports: | 4 x SATA |
- Specifications
- Description
| General | |
| Product Type: | Motherboard - mini ITX |
| Processor: | Intel Atom 330 (Dual-Core) |
| Chipset Type: | NVIDIA ION |
| Max Bus Speed: | 533 MHz |
| Supported RAM | |
| Max Size: | 4 GB |
| Technology: | DDR3 |
| Bus Clock: | 1066 MHz, 800 MHz |
| Speed: | PC3-8500, PC3-6400 |
| Supported RAM Integrity Check: | Non-ECC |
| Registered or Buffered: | Unbuffered |
| Features: | Dual channel memory architecture |
| Graphics | |
| Graphics Controller: | NVIDIA ION |
| Audio | |
| Type: | HD Audio (6-channel) |
| Audio Codec: | Realtek ALC887 |
| LAN | |
| Network Interfaces: | Gigabit Ethernet |
| Expansion / Connectivity | |
| Expansion Slots: | 2 x DIMM 240-pin ¦ 1 x PCIe x16 |
| Storage Interfaces: | SATA-300 -connectors: 4 x 7pin Serial ATA - 4 devices - RAID 0 / RAID 1 |
| Interfaces: | 1 x TOSLINK ¦ 1 x VGA ¦ 1 x HDMI ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x PS/2 keyboard ¦ 6 x USB 2.0 ¦ Audio |
| Additional Connectors (Optional): | 4 x USB 2.0 |
| Power Connectors: | 24-pin main power connector |
| Features | |
| BIOS Type: | AMI |
| BIOS Features: | DMI 2.0 support, WfM 2.0 support, ASUS EZ Flash 2, ASUS MyLogo3, ACPI 2.0a support, SMBIOS 2.5 support |
| Hardware Features: | ASUS Q-Fan, ASUS Home Theater Gate, NVIDIA CUDA Technology, Stack Cool 3+, CrashFree BIOS 3, ASUS AI NET2, ASUS Express Gate |
| Miscellaneous | |
| Cables Included: | 2 x Serial ATA cable |
| Software Included: | Drivers & Utilities, ASUS Live Update, ASUS PC Probe 2 |
| Compatible with Windows 7: | "Compatible with Windows 7" software and devices carry Microsoft’s assurance that these products have passed tests for compatibility and reliability with 32-bit and 64-bit Windows 7. |
| Compliant Standards: | Plug and Play, ACPI 2.0a |
| Width: | 17.1 cm |
| Depth: | 17.1 cm |
The technical details come from 3rd party. edgemo is not responsible for any errors.
